氣動元件
規格
| 用途 | 型式 (母頭) | 規格 | 圖例 | 型式 (公頭) | 規格 |
|---|---|---|---|---|---|
| 套管形 | SH20 | 5/16" | - | PH20 | 5/16" |
| SH30 | 3/8" | PH30 | 3/8" | ||
| SH40 | 1/2" | PH40 | 1/2" | ||
| SH60 | 3/4" | PH60 | 3/4" | ||
| SH80 | 1" | PH80 | 1" | ||
| 內牙形 | SF20 | 1/4PT | - | PF20 | 1/4PT |
| SF30 | 3/8PT | PF30 | 3/8PT | ||
| SF40 | 1/2PT | PF40 | 1/2PT | ||
| SF60 | 3/4PT | PF60 | 3/4PT | ||
| SF80 | 1PT | PF80 | 1PT | ||
| 外牙形 | SM20 | 1/4PT | - | PM20 | 1/4PT |
| SM30 | 3/8PT | PM30 | 3/8PT | ||
| SM40 | 1/2PT | PM40 | 1/2PT | ||
| SM60 | 3/4PT | PM60 | 3/4PT | ||
| SM80 | 1PT | PM80 | 1PT | ||
| 管帽形 | SP10 | Φ4*6 | - | PP10 | Φ4*6 |
| SP20 | Φ5*8 | PP20 | Φ5*8 | ||
| SP30 | Φ6.5*10 | PP30 | Φ6.5*10 | ||
| SP40 | Φ8*12 | PP40 | Φ8*12 |
